| MM-1…Ultra Miniature (smallest) Manual Stages - linear |
| MM-1X |
Manual translation stage, .125" travel. Single axis Sub miniature |
| MM-1X-VAC |
Manual transl stage, .125" travel. Single axis Vacumm Compatible |
| MM-1X-NP/VAC |
Manual transl stage, .125" travel. Single axis Vacumm Compatible, No Plating |
| MM-1XY-VAC |
Manual transl stage, .125" travel. 2-axis Vacumm Compatible |
| MM-1XY |
Manual translation stage, .125" travel 2-axis Sub miniature |
| MM-1XYZ |
Manual translation stage, .125" travel 3-axis Sub miniature |
| MM-1CR-X |
Manual Translation Stage, 0.125" Travel, Captured Rail |
| MM-1CR-XY |
Manual Translation Stage, 0.125" Travel, 2-axis, Captured Rail |
| MM-1CR-XYZ |
Manual Translation Stage, 0.125" Travel, 3-axis, Captured Rail |
| MM-1-EX-X |
Manual translation stage, .225" travel Sub miniature, single axis |
| MM-1-EX-XY |
Manual translation stage, .225" travel Sub miniature, two axis |
| MM-1-EX-XYZ |
Manual translation stage, .225" travel Sub miniature, three axis |
| MM-1-EX-XZ |
Manual translation stage, .225" travel Sub miniature, two axis |
| MM-1-SPR090 |
Manual translation stage, w/stronger return spring Sub miniature |
| MM-1R |
Man. Micro-Mini Rotary Stage w/.75" Table: Incl Course Adjust. Tool |
| PA-1 |
Pinhole adapter for MM-1 stage |
| TG-1 |
Knurled thumb grip for MM-1 stage |
| SS-1 |
Headless adjusting lead screw |
| AP4-1 |
Adapter mounting plate for optical bench |
| KIT-XY-1 |
X,Y screw kit for MM-1 |
| KIT-Z-1 |
Z brace and screw kit for MM-1 |
| ATK |
Assembly & mounting tool kit |
| JIG-XYZ-1 |
Alignment Construction Fixture for 2-3 Axis System |
| MM-2X Semi-Miniature Manual Stageses |
| MM-2CRB-X |
Manual translation stage, 5mm travel, Micrometer Head, X axis |
| MM-2CRB-XY |
Manual translation stage, 5mm travel, Micrometer Head, XY axis |
| MM-2CRB-XYZ |
Manual translation stage, 5mm travel, Micrometer Head, XYZ axis |
| MM-2CR-X |
Manual translation stage, Captured Rail, 5mm travel, X axis |
| MM-2CR-XY |
Manual translation stage, Captured Rail, 5mm travel, XY axis |
| MM-2CR-XYZ |
Manual translation stage, Captured Rail, 5mm travel, XYZ axis |
| MM-2CR-X-MIC |
Manual translation stage, Captured Rail 5mm travel, Micrometer Head, X axis |
| MM-2CR-XY-MIC |
Manual translation stage, Captured Rail 5mm travel, Micrometer Head, XY axis |
| MM-2CR-XYZ-MIC |
Manual translation stage, Captured Rail 5mm travel, Micrometer Head, XYZ axis |
| MM-2CR-XZ-MIC |
Manual translation stage, Captured Rail 5mm travel, Micrometer Head, XZ axis |
| MM-3…Miniature (larger) Manual Stages |
| MM-3CRB-X |
Manual translation stage, Butterfly Slider, .5" travel, Single axis miniature |
| MM-3CRB-XY |
Manual translation stage, Butterfly Slider, .5" travel, Two axis miniature |
| MM-3CRB-XYZ |
Manual translation stage, Butterfly Slider, .5" travel, Three axis miniature |
| MM-3X |
Manual translation stage, .5" travel, Single axis miniature |
| MM-3XY |
Manual translation stage, .5" travel, 2-axis miniature |
| MM-3XY-VAC |
Vacuum Compatible Manual Transl Stage, .5" Travel, 2-axis |
| MM-3XYZ |
Manual translation stage, .5" travel, 3-axis miniature |
| MM-3CR-X |
Manual translation stage, .5" travel., Captured Rail |
| MM-3CR-XY |
Manual translation stage, .5" travel., 2-Axis XY, Captured Rail |
| MM-3CR-XYZ |
Manual translation stage, .5" travel., 3-Axis, XYZ Captured Rail |
| MM-3XZ-VAC |
Vacuum Compatible Manual Transl Stage, .5" Travel, 2-axis |
| MM-3XZ-CR-SPEC |
Manual translation stage, .5" travel, 2-axis miniature(XZ) |
| MM-3M-CR-NTAP |
Modified/Custom MM-3MX with No Thumbscrews OR Tapped Holes |
| MM-3M-CR-NTS |
Modified/Custom MM-3MX with No Thumbscrews |
|
|
| Accessories |
|
| MM-3 MICROMETER |
Micrometer Head for MM-3 Manual Stage w/25mm Sensitivity |
| PA-3 |
Pinhole adapter for MM-3 stage |
| TG-3 |
Knurled thumb grip for MM-3 stage |
| SS-3 |
Headless adjusting lead screw |
| AP4-3 |
Adapter mounting plate for optical bench |
| OA-3 |
Objective adapter for MM-3 stage |
| KIT-XY-3 |
X,Y screw kit for MM-3 |
| KIT-Z-3 |
Z brace and screw kit for MM-3 |
| ATK |
Assembly & mounting tool kit |
| JIG-XYZ-3 |
Alignment fixture for 2-3 axis systems |
|
|
| MM-1M-F-5mm Motorized Stage |
| MM-1M-F-5mm |
Motorized Stage 64:1 Gear, 5mm Travel |
|
|
| MM-3M-ST… Motorized “MM3’s” (spring-preloaded slider) |
| MM-3M-ST |
Motorized standard stage, 64:1 gear, .5" travel |
| MM-3M-ST-XY |
Motorized standard stage, 64: gear .5” travel, 2 Axis |
|
|
|
|
|
|
|
|
|
|
|
|
| MM-3M-EX…Motorized Extended-motor Stages (miniature/smallest) |
| MM-3M-EX-.5 |
Motorized extended stage, 16:1 gear .5" travel |
| MM-3M-EX-.5-GR64 |
Motorized extended stage, 64:1 gear .5" travel |
| MM-3M-EX-.5-GR256 |
Motorized extended stage, 256:1 gear .5" travel |
| MM-3M-EX-.5-GR1024 |
Motorized extended stage, 1024:1 gear .5" travel |
| MM-3M-EX-1 |
Motorized extended stage, 16:1 gear 1" travel |
| MM-3M-EX-1-GR64 |
Motorized extended stage, 64:1 gear 1" travel |
| MM-3M-EX-1-GR256 |
Motorized extended stage, 256:1 gear 1" travel |
| MM-3M-EX-1-GR1024 |
Motorized extended stage, 1024:1 gear 1" travel |
| MM-3M-EX-1.5 |
Motorized extended stage, 16:1 gear 1.5" travel |
| MM-3M-EX-1.5-GR64 |
Motorized extended stage, 64:1 gear 1.5" travel |
| MM-3M-EX-1.5-GR256 |
Motorized extended stage, 256:1 gear 1.5" travel |
| MM-3M-EX-1.5-GR1024 |
Motorized extended stage, 1024:1 gear 1.5" travel |
| MM-3M-EX-2 |
Motorized extended stage, 16:1 gear 2" travel |
| MM-3M-EX-2-GR64 |
Motorized extended stage, 64:1 gear 2" travel |
| MM-3M-EX-2-GR256 |
Motorized extended stage, 256:1 gear 2" travel |
| MM-3M-EX-2-GR1024 |
Motorized extended stage, 1024:1 gear 2" travel |
|
|
| MM-3M-F… Folded-Motor Stages (miniature/smallest) |
| MM-3M-F-.5 |
Motorized folded stage, 16:1 gear .5" travel |
| MM-3M-F-.5-GR64 |
Motorized folded stage, 64:1 gear .5" travel |
| MM-3M-F-.5-GR256 |
Motorized folded stage, 256:1 gear .5" travel |
| MM-3M-F-.5-GR1024 |
Motorized folded stage, 1024:1 gear .5" travel |
| MM-3M-F-1 |
Motorized folded stage, 16:1 gear 1" travel |
| MM-3M-F-1-GR64 |
Motorized folded stage, 64:1 gear 1" travel |
| MM-3M-F-1-GR256 |
Motorized folded stage, 256:1 gear 1" travel |
| MM-3M-F-1-GR1024 |
Motorized folded stage, 1024:1 gear 1" travel |
| MM-3M-F-1.5 |
Motorized folded stage, 16:1 gear 1.5" travel |
| MM-3M-F-1.5-GR64 |
Motorized folded stage, 64:1 gear 1.5" travel |
| MM-3M-F-1.5-GR256 |
Motorized folded stage, 256:1 gear 1.5" travel |
| MM-3M-F-1.5-GR1024 |
Motorized folded stage, 1024:1 gear 1.5" travel |
| MM-3M-F-2 |
Motorized folded stage, 16:1 gear 2" travel |
| MM-3M-F-2-GR64 |
Motorized folded stage, 64:1 gear 2" travel |
| MM-3M-F-2-GR256 |
Motorized folded stage, 256:1 gear 2" travel |
| MM-3M-F-2-GR1024 |
Motorized folded stage, 1024:1 gear 2" travel |
| MM-3M-F-2.5 |
Motorized folded stage, 16:1 gear, 2.5" travel |
| MM-3M-F-2.5-GR64 |
Motorized folded stage, 64:1 gear, 2.5" travel |
| MM-3M-F-2.5-GR256 |
Motorized folded stage, 256:1 gear, 2.5" travel |
| MM-3M-F-2.5-1024 |
Motorized folded stage, 1024:1 gear, 2.5" travel |
|
|
| MM-3M-FOS… Folded-Motor Stages w/FlexureCarriage & Outside Slider: |
| MM-3M-FOS-2 |
Motorized, Folded, 2", w/Outside Slider, Flexure Carriage, 16:1gr |
| MM-3M-FOS-2-GR64 |
Motorized, Folded, 2", w/Outside Slider, Flexure Carriage, 64:1gr |
| MM-3M-FOS-2-GR256 |
Motorized, Folded, 2", w/Outside Slider, Flexure Carriage, 256:1gr |
| MM-3M-FOS-2-GR1024 |
Motorized, Folded, 2", w/Outside Slider, Flexure Carriage, 1024:1gr |
| MM-3M-FOS-2.5 |
Motorized, Folded, 2.5", w/Outside Slider, Flexure Carriage, 16:1gr |
| MM-3M-FOS-2.5-GR64 |
Motorized, Folded, 2.5", w/Outside Slider, Flexure Carriage, 64:1gr |
| MM-3M-FOS-2.5-GR256 |
Motorized, Folded, 2.5", w/Outside Slider, Flexure Carriage, 256:1gr |
| MM-3M-FOS-2.5-GR1024 |
Motorized, Folded, 2.5", w/Outside Slider, Flexure Carriage, 1024:1gr |
|
|
| MM-3G... Manual Gonimeters |
| MM-3GF-25 |
Manual Fine adjustment Goniometer, 25mm Radius |
| MM-3GF-42 |
Manual Fine adjustment Goniometer, 42mm Radius |
| MM-3GC-25 |
Manual Coarse adjustment Goniometer, 25mm Radius |
| MM-3GC-42 |
Manual Coarse adjustment Goniometer, 42mm Radius |
|
|
| MM-3M-R… Motorized Rotary Stage: |
| MM-3M-R |
Motorized miniature rotary stage, 64:1 gear |
| MM-3M-R-GR256 |
Motorized miniature rotary stage, 256:1 gear |
| MM-3M-R-GR1024 |
Motorized miniature rotary stage, 1024:1 gear |
| MM-3M-R-GR16HT |
Motorized miniature rotary stage, 16:1 gear, High-Torque Motor |
| MM-3M-RA |
Motorized miniature rotary stage, ultra low wobble, 64:1 gear |
| MM-3M-RA-GR256 |
Motorized miniature rotary stage, ultra low wobble, 256:1 gear |
| MM-3M-RA-GR1024 |
Motorized miniature rotary stage, ultra low wobble, 1024:1 gear |
| MM-3M-RA-GR16HT |
Motorized miniature rotary stage, 16:1 gear, High-Torque Motor |
| MM-3M-RA+ |
Motorized Miniature Rotary Stage, Ultra Low Wobble, 64:1 Gear, Plus 2 Arc-Sec Axial Angular Deviation |
| MM-3M-RA+-GR256 |
Motorized Miniature Rotary Stage, Ultra Low Wobble, 256:1 Gear, Plus 2 Arc-Sec Axial Angular Deviation |
| MM-3M-RA+1024 |
Motorized Miniature Rotary Stage, Ultra Low Wobble, 1024:1 Gear, Plus 2 Arc-Sec Axial Angular Deviation |
| MM-3M-RA+-GR16HT |
Motor mini rotary stage, UltraLow Wobble16:1, High-Torque Motor |
| MM-3M-R-STEPPER |
Motorized miniature rotary stage w/Stepper Motor 10mm 64:1 gear |
| 3M-R-FLT-MNT-PLT |
Optional custom flat mount adapter plate |
| 3M-R-RT-ANG-MNT-PLT |
Optional custom right angle mount adapter plate |
|
|
| MM-3M Accessories…Interfaces and attachments for miniature motor stages |
| BR-3M-CUST-BRKT |
Custom mounting bracket for MM-3M stages(priced per job) |
| BR-3M-ST |
Single or final axis slider brace for ST stage |
| BR-3M-X |
Single or final axis slider brace for all EX or F stages |
| BR-3M-XY-.5 |
X-Y axis interface & slider brace for EX-.5 or F-.5 stages |
| BR-3M-XZ-.5 |
X-Z axis interface & slider brace for F-.5 stages |
| BR-3M-XY-1 |
X-Y axis interface & slider brace for EX-1 or F-1 stages |
| BR-3M-XZ-1 |
X-Z axis interface & slider brace for F-1 stages |
| BR-3M-XY-1.5 |
X-Y axis interface & slider brace for EX-1.5 or F-1.5 stages |
| BR-3M-XZ-1.5 |
X-Z axis interface & slider brace for F-1.5 stages |
| BR-3M-XY-2 |
X-Y axis interface & slider brace for EX-2 or F-2 stages |
| BR-3M-XZ-2 |
X-Z axis interface & slider brace for F-2 stages |
| BR-3M-XY-2.5 |
X-Y axis interface & slider brace for EX-2 or F-2.5" stages |
| BR-3M-XZ-2.5 |
X-Z axis interface & slider brace for F-2.5" stages |
| AP4-3M |
Base adapter plate for -EX & -F stages to optical bench |
| AP4-3 |
Base adapter plate for -ST stage to optical bench |
| AP4-3M-FOS-XY |
Base adapter plate for -FOS stage to optical bench |
| AP4-3M-FOS-XZ |
Base adapter plate for -FOS stage to optical bench |
| AP4-3M-FOS |
Base adapter plate for -FOS stage to optical bench |
| PA-3 |
Pinhole adapter for MM-3M-ST stage |
| OA-3 |
Objective adapter for MM-3M-ST stage |
| KIT-XY-3 |
X,Y screw kit for MM-3M-ST |
| ATK |
Assembly & mounting tool kit |
| LS |
Replacement limit switch |
| LS-W |
Replacement hard wired limit switch |
| VAC-10mm |
Vacuum compatibility to 10-6 torr for 10mm motors |
| VAC-13mm |
Vacuum compatibility to 10-6 torr for 13mm motors |
| AB-OPTION |
Optional Anti-Backlash Option (2-4 microns) |
| TEFLON |
Teflon cable upgrade to motorized stage |
| GR-16K |
16:1 Gearhead w/Bearing for 10mm Motor |
| GR-64K |
64:1 Gearhead w/Bearing for 10mm Motor |
| GR-256K |
256:1 Gearhead w/Bearing for 10mm Motor |
| GR-1024K |
1024:1 Gearhead w/Bearing for 10mm Motor |
| MTR-10mm |
10mm Motor, (no encoder) |
| MTR-10-E |
10mm Motor, w/10-Position Encoder |
| MTR-13-E |
13mm Motro w/16-Position Encoder, 14:1 Gearhead |
| MTR-13-E-GR66 |
13mm Motor, w/16-Position Encoder,66:1 Gearhead |
| MTR-13-E-GR256 |
13mm Motor, w/16-Position Encoder, 256:1 Gearhead |
| MTR-10MM-STEPPER |
10mm Stepper Motor, No Encoder |
| MTR-HT-UPGRD-GR16 |
10mm High-torque, 12-Position Encoder, 16:1 Gear |
| MTR-HT-UPGRD-GR64 |
10mm High-torque, 12-Position Encoder, 64:1 Gear |
| MTR-HT16-UPGRD-GR64 |
10mm High-torque, 16-Position Encoder, 16:1 Gear |
| MTR-HT256-UPGRD-GR64 |
10mm High-torque, 256-Position Encoder, 16:1 Gear |
|
|
|
|
|
|
|
|
| MM-4M-EX… Extended-Motor Stages (miniature/next larger) – takes 13 mm motor |
| MM-4M-EX-50mm-GR3.71 |
Motorized extended stage, 3.71:1 gear, 48mm travel |
| MM-4M-EX-50mm-GR14 |
Motorized extended stage, 14:1 gear, 48mm travel |
| MM-4M-EX-50mm-GR43 |
Motorized extended stage, 43:1 gear, 48mm travel |
| MM-4M-EX-50mm-GR66 |
Motorized extended stage, 66:1 gear, 48mm travel |
| MM-4M-EX-80mm-GR14 |
Motorized extended stage, 14:1 gear, 78mm travel |
| MM-4M-EX-80mm-GR43 |
Motorized extended stage, 43:1 gear, 78mm travel |
| MM-4M-EX-80mm-GR66 |
Motorized extended stage, 66:1 gear, 78mm travel |
| MM-4M-EX-110mm-GR14 |
Motorized extended stage, 14:1 gear, 108mm travel |
| MM-4M-EX-110mm-GR43 |
Motorized extended stage, 43:1 gear, 108mm travel |
| MM-4M-EX-110mm-GR66 |
Motorized extended stage, 66:1 gear, 108mm travel |
| MM-4M-EX-140mm-GR14 |
Motorized extended stage, 14:1 gear, 138mm travel |
| MM-4M-EX-140mm-GR43 |
Motorized extended stage, 43:1 gear, 138mm travel |
| MM-4M-EX-140mm-GR66 |
Motorized extended stage, 66:1 gear, 138mm travel |
| MM-4M-EX-140mm-OPPOSE |
MM-4M-EX-140 w/Dual Carriage and Opposing Lead Screw |
| MM-4M-EX-170mm-GR14 |
Motorized extended stage, 14:1 gear, 168mm travel |
| MM-4M-EX-170mm-GR43 |
Motorized extended stage, 43:1 gear, 168mm travel |
| MM-4M-EX-170mm-GR66 |
Motorized extended stage, 66:1 gear, 168mm travel |
| MM-4M-EX-200mm-GR14 |
Motorized extended stage, 14:1 gear, 198mm travel |
| MM-4M-EX-200mm-GR43 |
Motorized extended stage, 43:1 gear, 198mm travel |
| MM-4M-EX-200mm-GR66 |
Motorized extended stage, 66:1 gear, 198mm travel |
| MM-4M-EX-230mm-GR14 |
Motorized extended stage, 14:1 gear, 228mm travel |
| MM-4M-EX-230mm-GR43 |
Motorized extended stage, 43:1 gear, 228mm travel |
| MM-4M-EX-230mm-GR66 |
Motorized extended stage, 66:1 gear, 228mm travel |
| MM-4M-EX-260mm-GR14 |
Motorized extended stage, 14:1 gear, 258mm travel |
| MM-4M-EX-260mm-GR43 |
Motorized extended stage, 43:1 gear, 258mm travel |
| MM-4M-EX-260mm-GR66 |
Motorized extended stage, 66:1 gear, 168mm travel |
|
|
| MM-4M-F's…Folded-Motor Stages (miniature/next larger) |
| MM-4M-F-25mm-GR64* |
Motorized folded stage, 64:1 gear, 25mm travel *Default |
| MM-4M-F-25mm-GR256 |
Motorized folded stage, 256:1 gear, 25mm travel |
| MM-4M-F-25mm-GR1024 |
Motorized folded stage, 1024:1 gear, 25mm travel |
| MM-4M-F-50mm-GR64* |
Motorized folded stage, 64:1 gear, 50mm travel *Default |
| MM-4M-F-50mm-GR256 |
Motorized folded stage, 256:1 gear, 50mm travel |
| MM-4M-F-50mm-GR1024 |
Motorized folded stage, 1024:1 gear, 50mm travel |
|
|
|
|
|
|
| MM-4M-R… Motorized Rotary Stages (miniature/next larger) – takes 13 mm motor |
| MM-4M-R |
Motorized rotary stage, w/2 inch dia. table, 14:1 gear |
| MM-4M-R-GR66 |
Motorized rotary stage, w/2 inch dia. table, 66:1 gear |
| MM-4M-R-STEPPER |
Motorized rotary stage w/Stepper Motor, 2-inch dia. table, 14:1 gear, 16mm |
| MM-4M-FLT-MNT-PLT |
Optional custom flat mount adapter plate |
| MM-4M-RT-ANG-MNT-PLT |
Optional custom right angle mount adapter plate |
| MM-4M Accessories… Interfaces and attachments for miniature motor stages |
| BR-4M-XY-25mm |
X-Y axis interface for MM-4M-F-25mm stage |
| BR-4M-XY-50mm |
X-Y axis interface for MM-4M-F-50mm stage |
| BR-4M-XZ-25mm |
X-Z axis interface for MM-4M-F-25mm stage |
| BR-4M-XZ-50mm |
X-Z axis interface for MM-4M-F-50mm stage |
| BR-4M-CUST-BRKT |
Custom mounting bracket for MM-4M stages(priced per job) |
| AP4-4M |
Base adapter plate for -EX & -F (to 50mm) stages to optical bench |
| AP4-4M-EX-170 |
Adapter Plate for -EX-50mm to 170mm Stages to Optical Bench |
| AP4-4M-EX-260 |
Adapter Plate for -EX-50mm to 260mm Stages to Optical Bench |
| AP4-4M-140-ORTHO |
10" x 10" Orthogonal/Gantry Adapter Plate for -EX-50mm to 140mm Stages to Optical Bench |
| AP4-4M-140-260-ORTHO |
14" x 14" Orthogonal/Gantry Adapter Plate for -EX-50mm to 260mm Stages to Optical Bench |
| VAC-10mm |
Vacuum compatibility to 10-6 torr for 10mm motors |
| VAC-13mm |
Vacuum compatibility to 10-6 torr for 13mm motors |
| MM-4M-EX-SUP-MNT-80 |
Optional support slide mount for MM-4M-EX-80 |
| MM-4M-EX-SUP-MNT-110 |
Optional support slide mount for MM-4M-EX-110 |
| MM-4M-EX-SUP-MNT-140 |
Optional support slide mount for MM-4M-EX-140 |
| MM-4M-EX-SUP-MNT-170 |
Optional support slide m+B26ount for MM-4M-EX-170 |
| MM-4M-DUAL-CARRIAGE |
MM-4M-EX dual carriage option |
| MISC. ITEM |
Misc. Item (Price per item requirements) |
|
|
| Motorized Goniometers |
|
| MM-4M-G-87 |
87mm Radius Motorized Goniometer |
| MM-4M-G-87-R |
87mm Radius Motorized Goniometer with Renishaw Encoder |
| MM-4M-G-120 |
120mm Radius Motorized Goniometer |
| MM-4M-G-120-R |
120mm Radius Motorized Goniometer with Renishaw Encoder |
| MM-4M-G-MTRKIT |
Motor Kit for the 87mm and 120mm goniometers |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| HD-6M-MM… Motorized Linear Stages (largest Linear Stage) |
| HD-6M-50MM |
Heavy Duty Motorized Linear Stage 50mm Travel, 125mm/s |
| HD-6M-100MM |
Heavy Duty Motorized Linear Stage 100mm Travel, 125mm/s |
| HD-6M-150MM |
Heavy Duty Motorized Linear Stage 150mm Travel, 125mm/s |
| HD-6M-200MM |
Heavy Duty Motorized Linear Stage 200mm Travel, 125mm/s |
| HD-6M-250MM |
Heavy Duty Motorized Linear Stage 250mm Travel, 125mm/s |
| HD-6M-300MM |
Heavy Duty Motorized Linear Stage 300mm Travel, 125mm/s |
| MM-6M Accessories… Interfaces and attachments for miniature motor stages |
| BR-6M-Z-50MM |
Z-Axis Slider Brace for HD-6M-50MM |
| BR-6M-Z-100MM |
Z-Axis Slider Brace for HD-6M-100MM |
| BR-6M-Z-150MM |
Z-Axis Slider Brace for HD-6M-150MM |
| BR-6M-Z-200MM |
Z-Axis Slider Brace for HD-6M-200MM |
| BR-6M-Z-250MM |
Z-Axis Slider Brace for HD-6M-250MM |
| BR-6M-Z-300MM |
Z-Axis Slider Brace for HD-6M-300MM |
| AP6-6M |
Metric Top Plate for HD-6M-xx Stage |
| AP6-6S |
Standard Top Plate for HD-6M-mm Stage |
| AP6-6B |
Blank Top plate for HD-6M-xx Stage |
| HD-LINEAR-ENCODER |
0.1micron Linear Encoder |
| CA-HD-CBL-MVP |
HD-6M-xxMM to MVP Controller Interface Cable |
| CA-HD-CBL-NI |
HD-6M-xxMM-to NI Amplifier Interface Cable |
| Motors /Gearheads… |
|
| MTR-10 |
10mm motor, no encoder |
| MTR-10-E |
10mm motor, w/ 10 position encoder |
| MTR-HT-UPGRD-GR16 |
10mm High-Torque DC Servo Motor, 12-Pos Encoder, 16:1GH, Field Units Only |
| MTR-HT-UPGRD-GR64 |
10mm High-Torque DC Servo Motor, 12-Pos Encoder, 64:1GH, Field Units Only |
| MTR-13-E |
13mm motor, w/14:1 gearhead, w/ 16 position encoder |
| MTR-13-E-GR66 |
13mm Motor w/16-Position Encoder and 66:1 Gear |
| MTR-13-E-GR246 |
13mm Motor w/16-Position Encoder and 246:1 Gear |
| GR4K |
4:1 gearhead w/bearing for 10mm motor |
| GR16K |
16:1 gearhead w/bearing for 10mm motor |
| GR64K |
64:1 gearhead w/bearing for 10mm motor |
| GR256K |
256:1 gearhead w/bearing for 10mm motor |
| GR1024K |
1024:1 gearhead w/bearing for 10mm motor |
| Stand-Alone Controllers… With display and user interface. –serial controllable |
| DIFF-SE-INTFC |
Differential to Single-Ended Conversion Package (Add DIFF Cable) |
| 110-0019 |
Linear Driver: Single Ended-to-Differential Converter |
| 110-0020 |
Linear Driver: Single Ended-to-Differential Converter |
| MC-5B |
Manual Single/Multi-Axis Servo Controller w/Display |
| MC-4B-3000 OEM |
MC-4B-3000 w/Main Bd, & Heatsink Only, No Kybd, Case, Display. |
| MC-4B-Servo 1000 |
Manual, single axis servo controller with display |
| MC-4B-Servo 2000 |
Manual, single axis servo controller with display |
| MC-4B-Servo 3000 |
Manual, single axis servo controller with display |
| Field upgrade 1-2 |
Key code to upgrade Servo 1000 to Servo 2000 |
| Field upgrade 2-3 |
Key code to upgrade Servo 2000 to Servo 3000 |
| Field upgrade 1-3 |
Key code to upgrade Servo 1000 to Servo 3000 |
| MC-4B-DOC |
Additional printed manual for MC-4B |
| MC-5B-DOC |
Additional printed manual for MC-5B |
| MC-5B/4B-Encoder-Wheel |
1-Axis Precision Rotary Encoder Wheel for MC-5B/4B Controller |
| MC-5B/4B-JOYSTICK |
2-Axis, 2-Speed, Precision Joystick Manual Ctrl for MC-5B/4B Ctrlr |
| CA-MC-4B-NTWK |
Motion-NET Network Node Interface Cable for MC-5B/4B Integration |
| MC-4B-CTRL-MASTER |
Multi-Axis MC-4B Automated Position Control System for 2-99 MC-4B |
| MC-5B/4B-TRANSFORMER |
MC-5B/4B Optional Transformer (xxV/xxHZ) |
|
|
| MicroMini Controllers… No display or user interface – advanced command set – stand alone ability |
| IMS-MOTION-CTRL-SFTWR |
Intelligent Motion Systems 4-Axis Motion Control Console. |
| IMS-JOYSTICK-4-CABLED |
4-Axis Logitech Cabled RumblePad-2 Joystick Programmed For Intelligent Motion Systems Motion Control Software. |
| IMS-JOYSTICK-4-WIRELESS |
4-Axis Logitech Wireless RumblePad-2 2.4Ghz Joystick Programmed For Intelligent Motion Systems Motion Control Software. |
| MC-CQ-A |
1-Axis, RS232, DC-Servo PWM Controller/Amplifier, CE-Marked, RoHS-Compliant |
| MC-CQ-B |
1-Axis, RS232, DC-Servo PWM Controller/Amplifier, CE-Marked, RoHS-Compliant |
| MC-CQ-4X-4 |
4-Axis, RS232, DC-Servo PWM Controller/Amplifier, CE-Marked, RoHS-Compliant |
| MC-CQ-4X-RACKMNT |
Rack Mount for 4 Axis MC-CQ |
| MC-CQ-SER-TO-USB-1 |
1-Port RS232 DB-9 to USB Serial Converter Interface |
| MC-CQ-SER-TO-USB-2 |
2-Port RS232 DB-9 to USB Serial Converter Interface |
| MC-CQ-SER-TO-USB-4 |
4-Port RS232 DB-9 to USB Serial Converter Interface |
| MC-CQ-SER-TO-USB-8 |
8-Port RS232 DB-9 to USB Serial Converter Interface |
| MC-CQ-USB-RACKMNT |
Rack Mount for SER-TO-USB 4 Axis and 8 Axis |
| MVP-1-1A |
Single axis, RS-232 integrated servo system |
| MVP-1-2A |
2 axis, RS-485 integrated servo system |
| MVP-1-3A |
3 axis, RS-485 integrated servo system |
| MVP-1-4A |
4 axis, RS-485 integrated servo system |
| MVP-1-AA |
Additional axis, RS-485 integrated servo system |
| MVP-RS-485 |
RS-485 converter module (required for multi axis opertion) |
| MVP-PWM-1A |
PWM-A 1-Axis, RS-232, Integrated DC-Servo Controller/Amplifier |
| MVP-PWM-2A |
PWM-A 2-Axis, RS-485, Integrated DC-Servo Controller/Amplifier |
| MVP-PWM-3A |
PWM-A 3-Axis, RS-485, Integrated DC-Servo Controller/Amplifier |
| MVP-PWM-4A |
PWM-A 4-Axis, RS-485, Integrated DC-Servo Controller/Amplifier |
| MVP-PWM-AA |
Addtl 1-Axis RS-485 Integrated Servo Cntrlr, Daisy Cbl, 24v, 4A, 90w |
| MVP-PWM-1A-ES |
1-Axis RS-485 Integrated Servo Cntrlr, Daisy Cbl, 24v, 4A, 90w |
| MVP-PS-24 |
24V Power Supply for the MVP Controllers |
| RS-485-2 |
RS-485 2-Axis Communications Daisy Cable |
| RS-485-4 |
RS-485 4-Axis Communications Daisy Cable |
| RS-485-6 |
RS-485 6-Axis Communications Daisy Cable |
| RS-485-8 |
RS-485 8-Axis Communications Daisy Cable |
| DIFF-SE-INTFC |
Differential to Single-Ended Conversion Package (Add DIFF Cable) |
| 110-0019 |
Linear Driver: Single Ended-to-Differential Converter |
| 110-0020 |
Linear Driver: Single Ended-to-Differential Converter |
| CA-MVP-1 |
12" Single axis stage interface cable |
| CA-MVP-2 |
24" Single axis stage interface cable |
| CA-MVP-18 |
18" Single Axis Stage Interface Cable |
| CA-MVP-3 |
36" Single axis stage interface cable |
| PS-24VDC |
24 volt power supply for MVP |
| DB9-J1 |
RS-232, 9 pin, male, IDC connector |
| MVP-DOC |
Additional printed manual for MVP |
|
|
| NI Controllers… (National Instruments, LabView compatible, coordinated motion controllers) |
| PCI-7342 |
2-Axis Motion Controll 32-Bit PCI (See cables below) |
| PCI-7344 |
4 axis, 32-bit PCI flex motion with I/O (see cables below) |
| PXI-7344 |
4 axis, 32-bit PXI flex motion with I/O (see cables below) |
| FW-7344(also for MAC) |
4 axis, 32-bit FireWire flex motion with I/O (see cables below) |
| 778553-01 |
NI Motion Assistant Software |
| PXI-7350 |
8-Axis, Servo/Stepper Amplifier |
| 185630-01 |
NI Cable Adapter, 68 to 50 pin (for use with 7344 controllers) |
| 186381-02 |
NI SH68 – C68-S cable, 2 m (for use with 7344 controllers) |
| CA-50-50-3 |
3-Foot, 50-Pin Interface Cable to PCI-SERVO-4A Controller |
| NAI Amplifiers… (compatible with National Instruments controllers) |
| MC-3-BRA |
Single (additional axis module for Servo Amplifier ) |
| MC-4SA |
4-Axis Multi-functio servo amplifier |
| MC-4SA-RACKMNT-OPT |
19" Rack Mount Option for MC-4SA Amplifier |
| DIFF-SE-INTFC |
Differential to Single-Ended Conversion Package (Add DIFF Cable) |
| Cabling … |
|
| CA10-10-2 |
2 ft. motor cable extension |
| CA10-10-3 |
3 ft. motor cable extension |
| CA10-10-4 |
4 ft. motor cable extension |
| CA10-10-6 |
6 ft. motor cable extension |
| CA10-10-7 |
7 ft. motor cable extension |
| CA10-10-9 |
9 ft. motor cable extension |
| CA10-10-15 |
15 ft. motor cable extension |
| CA-10-10-1-VAC |
1-Foot, 10-Conductor Teflon Ribbon Cable: Vacuum Compatible |
| CA-10-10-2-VAC |
2-Foot, 10-Conductor Teflon Ribbon Cable: Vacuum Compatible |
| CA-10-10-3-VAC |
3-Foot, 10-Conductor Teflon Ribbon Cable: Vacuum Compatible |
| CA-10-10-5-VAC |
5-Foot, 10-Conductor Teflon Ribbon Cable: Vacuum Compatible |
| CA-10-10-7-VAC |
7-Foot, 10-Conductor Teflon Ribbon Cable: Vacuum Compatible |
| CA10-MINIDIN-3 |
3-Foot, Round Extension Cable with M/F Minidin Connector |
| CA10-MINIDIN-6 |
6-Foot, Round Extension Cable with M/F Minidin Connector |
| CA10-MINIDIN-9 |
9-Foot, Round Extension Cable with M/F Minidin Connector |
| DIFF-CBL-20C-20 |
20Ft. Differential Cable, 20 Conductor, w/DB-Male to DB-Female |
| DIFF-CBL-20C-30 |
30Ft. Differential Cable, 20 Conductor, w/DB-Male to DB-Female |
| DIFF-CBL-20C-50 |
50Ft. Differential Cable, 20 Conductor, w/DB-Male to DB-Female |
| DIFF-CBL-20C-75 |
75Ft. Differential Cable, 20 Conductor, w/DB-Male to DB-Female |
| DIFF-CBL-20C-100 |
100Ft. Differential Cable, 20 Conductor, w/DB-Male to DB-Female |
線陣CCD光纖光譜儀
